FlowCon Energy FIT System



FlowCon FIT-G
DN15-50 (1/2"-2")

  • State-of-the-art pressure independent balancing and temperature control (PITCV)
  • Cost savings due to optimized energy consumption, improved efficiency and ΔT control
  • Simple monitoring via Bluetooth® or analog to BMS via BACnet
  • Communicates to FlowCon App (iOS or Android)
  • All in one system including PICV, Intelligent Interface and sensor kit
  • Actuator on PICV
    • FN.0.2 actuator (DN15-32 / 1/2"-1 1/4"): electrical 2-10V modulating
    • FH actuators (DN40-50/ 1 1/2"-2"): electrical 2-10V modulating, optional failsafe
  • Adjustable to 41 different maximum flow rate limits
  • Intelligent Interface with integrated BTU meter and flow meter
  • Sensor kit including either 2 temperature sensors and 2 pressure sensors or a simple sensor kit including merely 2 temperature sensors
  • DN15-25: DZR brass PICV housing and stainless steel sensors
    DN25-50: Forged brass PICV housing and stainless steel sensors
    DN40-50: Ductile iron PICV housing and stainless steel sensors
  • PICV fixed female-by-female threaded connection

Pressure rate:
PN25

Sizes:
DN15-50 (1/2"-2")

ΔP-range:
16-800 kPaD (2.3-116 psid)

Flow rate:
0.0103-3.79 l/sec (0.163-60.0 GPM)

FlowCon FIT
DN15-250 (1/2"-10")

  • State-of-the-art pressure independent balancing and temperature control (PITCV)
  • Cost savings due to optimized energy consumption, improved efficiency and ΔT control
  • Simple monitoring via Bluetooth® or analog to BMS via BACnet
  • Communicates to FlowCon App (iOS or Android)
  • All in one system including PICV, Intelligent Interface and sensor kit
  • State-of-the-art user-friendly programmable display actuator on PICV
    • SM actuators: electrical 2-10V modulating, optional failsafe and optional BACnet
  • Adjustable to minimum 51 different maximum flow rate limits
  • Intelligent Interface with integrated BTU meter and flow meter
  • Sensor kit including 2 temperature sensors and 2 pressure sensors
  • DN15-40: Forged brass PICV housing and stainless steel sensors
    DN50-250: Ductile iron PICV housing and stainless steel sensors
  • DN15-40: PICV with double union end connection
    DN50-250; PICV with universal flange connection

Pressure rate:
DN15-40: PN25
DN50-250: PN40

Sizes:
DN15-250 (1/2"-10")

ΔP-range:
30-800 kPaD (4.4-116 psid)

Flow rate:
0.176-76.8 l/sec (2.78-1220 GPM)
