FlowCon ADP
DN15-25 (1/2"-1")
- Integrated differential pressure control valve and differential pressure controller (combi PICV and DPCV)
- Serviceable
- 3-in-one
- FT actuator: thermal ON/OFF, standard failsafe
- 41 different stepless ΔpC settings
- Forged brass or DZR brass housing DN15/20/25 (1/2”-1”)
- Optional pressure/temperature plugs
- Fixed female-by-female threaded
- Max. operational ΔP: 500 kPaD (72 psid)
Sizes:
DN15-25 (1/2"-1")
ΔpC-range:
ADP.0: 3-17 kPaD (0.4-2.5 psid)
ADP.1: 3-35 kPaD (0.4-5.1 psid)
Flow rate:
ADP.0: 9-680 l/hr (0.040-2.99 GPM)
ADP.1: 26-1100 l/hr (0.115-4.84 GPM)
Partner valve:
FlowCon Partner Ball
FlowCon Insert Concept
The modular construction gives you:
Easy selection - Easy setting - Easy maintenance
- Are you looking for full flexibility?
- Do you want a full serviceable solution?
- Will simple flushing be a benefit in your HVAC system?
- Are you interested in reduced commissioning time?
- Do you look at circularity and simple waste handling?
#MyFavoriteFlowCon
Some FlowCon ADP Projects (DPCV)
Se all projects
Cactus Towers, Copenhagen, Denmark
"Micro-living" youth housing in the heart of Copenhagen. Efficient and sustainable - this goes for building design and the choice of FlowCon valves
High Garden in Parisian suburb’s eco-district, France
The new complex will include 250 apartments and a French-style convenience store – with FlowCon PICV and DPCV
New Terminal at Hangzhou Xiaoshan International Airport, China
Huge project providing double terminal area to handle triple number of air travelers
New Tobolsk Airport in Siberia, Russia
To obtain better temperature control in the terminal building and associated buildings, FlowCon DPCV and dynamic balancing valves are installed…
PRIME PARK in City of Moscow
9 towers for mixed use and high-end residential accommodation – new tower is also supplied with FlowCon valves
Kashirskaya Plaza, Moscow, Russia
2018 largest shopping center project in Moscow - with FlowCon dynamic balancing
