FlowCon Green

FlowCon Green.0/1/1HF/2
DN15-32 (1/2"-1 1/4")

  • Pressure independent balancing and control valves (PIBCV/PICV)
  • Total authority
  • Choice of actuator:
    • FN actuators: electrical 0(2)-10V modulating, 3-point floating or 2-position, optional BACnet or Modbus
    • FNP actuators: electrical 0(2)-10V modulating
    • FNR actuators: electrical 0-10V modulating, 3-point floating or 2-position
    • FNJ actuators: electrical 0-10V modulating, failsafe
    • FT actuators: thermal 0-10V modulating or ON/OFF, standard failsafe
  • Adjustable to 41 different maximum flow rate limits
  • Forged brass or DZR brass housing DN15/20/25 (1/2”-1”) and forged brass housing DN25/32 (1”-1 1/4”)
  • Optional pressure/temperature plugs
  • Fixed female-by-female threaded

Pressure rate:
PN25

Sizes:
Green.0/1/1HF: 20 mm (3/4"), applicable for DN15/20/25 (1/2", 3/4", 1") valves
Green.2: 40 mm (1 1/2"), applicable for DN25/32 (1", 1 1/4") valves

ΔP-range:
16-800 kPaD (2.3-116 psid)

Flow rate:
0.0103-1.29 l/sec (0.163-20.4 GPM)

FlowCon Green.3
DN40-50 (1 1/2"-2")

  • Pressure independent balancing and control valves (PIBCV/PICV)
  • Total authority
  • Choice of actuator:
    • FH actuators: electrical 0(2)-10V modulating, 2-position or 3-point-floating, optional failsafe and optional BACnet or Modbus
  • Adjustable to 41 different maximum flow rate limits
  • Forged brass housing or ductile iron housing
  • Optional pressure/temperature plugs
  • Fixed female-by-female threaded

Pressure rate:
PN25

Sizes:
Green.3: 40-50 mm (1 1/2"-2")

ΔP-range:
16-800 kPaD (2.3-116 psid)

Flow rate:
0.528-3.79 l/sec (8.36-60.0 GPM)

My Favorite FlowCon Product by FlowCon Sales Manager Latin America Mario Silva

FlowCon Green.1 High Flow

by Mario Silva, Area Sales Manager, FlowCon International, USA

#MyFavoriteFlowCon

FlowCon Green animation - HVAC

Take a Tour inside FlowCon Green

Learn how the FlowCon Green insert is installed, set and actuator mounted. See how the Green insert’s rolling diaphragm technology works. And finally understand how the Green insert functions together with its actuator and works as a true PICV during any operation situation.

The animation shows in inner working of the FlowCon Green.2 but represents all Green inserts in the range.



Thobias Schlatter, Taconova Teamleader Systems states:

Both the DPCV-valve FlowCon EDP and the PICV-valve FlowCon Green come with several benefits and are the ideal integrators in our solutions. The FlowCon valves simply offer everything that dynamic balancing requires in a simple, convenient and efficient way. They are compact, flexible and easy to use. This ideally complements our system concept of intuitive technology - it couldn't be better”.



Taconova and FlowCon have worked together for years on the DPCV and PICV market.
