01.2019

New FlowCon FH.1 Failsafe Actuator
- for FlowCon Green.3 (PICV)

FlowCon introduces the failsafe FH version. The new actuator - called FH.1 - will match the FlowCon Green.3 valves. The new FlowCon FN.1.2-actuator holds the following features:

  • Failsafe option:
    Select either failsafe close or failsafe open on the actuator.
  • Simple selection - All control modes in 1:
    The new version will include 24V modulation and 2-position in one and the same actuator.
  • Flexible solution - Selectable control characteristic:
    Linear flow or equal percentage to be selected directly on the actuator. Hence, control characteristic for the valve may be determined late and even after installation.
  • Easy installation - Upside-down:
    The new version allows upside-down installation making 360° installation possible.
  • Built-in safety - Electrical override:
    The new version includes an integrated electrical override function. Automatic re-calibration will always follow deactivation of override.
  • Faster run time:
    Normal operation run time is 22 sec/mm but in failsafe mode run time is only 5 sec/mm.
