FlowCon EVS

DN15-25 (1/2"-1")

  • Dynamic balanced temperature control valves (BTCV/TCV)
  • Accessible, removeable pre-set stainless steel insert
  • Serviceable
  • Choice of actuator:
    • EV actuators: thermal 0-10V modulating or ON/OFF, standard failsafe – optional end switch
  • Forged brass or DZR brass housing DN15/20/25 (1/2”-1”)
  • Optional pressure/temperature plugs (AB)
  • Fixed female-by-female threaded

EVS: 20 mm (3/4") insert for 20 mm (3/4”) stainless steel insert, applicable for DN15/20/25 (1/2"-1") valves

ΔP range:
10-390 kPaD (1-57 psid)

Flow rate:
0.021-0.631 l/sec (0.333-10.0 GPM)

FlowCon EVS animation - HVAC

Take a Tour inside FlowCon EVS

Learn how the FlowCon EVS is fitted with its stainless steel insert and how EVS is installed in its valve housing and actuator mounted. See how the stainless steel insert’s moving cup technology works. And finally understand how the EVS functions together with its actuator and works ON/OFF allowing design flow or no flow at all.

My Favorite FlowCon Product by FlowCon Sales Manager Europe Søren Christensen

FlowCon Insert Concept

The modular construction gives you:
Easy selection - Easy setting - Easy maintenance

  • Are you looking for full flexibility?
  • Do you want a full serviceable solution?
  • Will simple flushing be a benefit in your HVAC system?
  • Are you interested in reduced commissioning time?
  • Do you look at circularity and simple waste handling?
